APC by Schneider Electric Easy UPS On-Line Double Conversion Online UPS - 3 kVA/2.70 kW

  • Part: 1627644
  • Model: SRVL3KRILRK
$4,909.09

Availability

Out of Stock

  • General Information
    • Manufacturer
    • Schneider Electric SA
    • Manufacturer Website Address
    • http://www.schneider-electric.com.au
    • Brand Name
    • APC by Schneider Electric
    • Product Line
    • Easy UPS On-Line
    • Product Series
    • SRVL
    • Packaged Quantity
    • 1
    • Product Type
    • Double Conversion Online UPS
  • Warranty
    • Additional Warranty Information
    • 3 years UPS repair or replace; 5 years battery repair or replace

  • Technical Information
    • Plug/Connector Type
    • IEC 60320 C20
    • Receptacle Type
    • IEC 60320 C13
    • IEC 60320 C19
    • Receptacle Detail
    • 6 x IEC 60320 C13
    • 1 x IEC 60320 C19
    • Phase
    • Single Phase
    • Application/Usage
    • Surveillance System
    • Banking
    • POS
    • Healthcare
    • IT
    • Data Center
    • Server Room
  • Power Description
    • Load Capacity (VA)
    • 3 kVA
    • Load Capacity (Watt)
    • 2.70 kW
    • Input Voltage
    • 120 V AC
    • 230 V AC
    • Input Voltage Range
    • 160 V AC - 300 V AC
    • 110 V AC - 300 V AC
    • Output Voltage
    • 220 V AC
    • 230 V AC
    • 240 V AC
    • Input Frequency
    • 70 Hz
    • Output Frequency
    • 60 Hz
    • Waveform Type
    • Sine Wave
    • Surge Energy Rating
    • 945 J
    • Output Power Factor
    • 0.9
  • Display & Graphics
    • Display
    • LCD
  • Management
    • Alarm
    • On Battery
    • Low Battery
    • Overload
  • Interfaces/Ports
    • Serial Port
    • Yes
    • Network (RJ-45)
    • Yes
    • USB
    • Yes
    • EPO Port
    • Yes
  • Battery Information
    • Battery Chemistry
    • Lithium Ion (Li-Ion)
    • Battery Size
    • 48V
    • Backup/Run Time (Full Load)
    • 45 Minute
    • Backup/Run Time (Half Load)
    • 1.47 Hour
    • Battery Life
    • 10 Year
    • Typical Battery Recharge Time
    • 4.80 Hour
  • Environmental Conditions
    • Storage Temperature
    • -20°C - 50°C
    • Maximum Operating Elevation
    • 3 km
    • Maximum Storage Elevation
    • 15 km
    • Storage Relative Humidity
    • 0% - 95%
    • Sound Emission (A-Weighted)
    • 50 dB(A)
  • Physical Characteristics
    • Color Family
    • Dual Colour
    • Product Color
    • Black
    • Silver
    • Height
    • 172 mm
    • Width
    • 438 mm
    • Depth
    • 616 mm
    • Rack Height
    • 4U
    • Form Factor
    • Rack/Tower
    • Weight (Approximate)
    • 38.30 kg
  • Miscellaneous
    • Environmentally Friendly
    • Yes
