Eaton Line-interactive UPS - 3 kVA/3 kW

  • Part: 1425819
  • Model: 5PX3000IRT3UAUG2
$4,721.00

Availability

In Stock

  • General Information
    • Manufacturer
    • Eaton Corporation
    • Manufacturer Website Address
    • http://www.eatoncorp.com.au
    • Brand Name
    • Eaton
    • Product Series
    • 5PX G2
    • Product Type
    • Line-interactive UPS

Exceptional efficiency, manageability and energy metering capabilities for IT managers | Performance and efficiency

  • With unity power factor output (W=VA), Eaton 5PX Gen 2 provides 11% more power than other UPS in its class, protecting more servers with a single unit.
  • Energy Star 2.0 certified, 5PX Gen 2 offers best-in-class efficiency performance to reduce energy consumption and cooling costs.
  • When operating in battery mode the 5PX provides a high-quality output signal for any sensitive equipment connected, such as active PFC (power factor corrected) servers.
  • Each 5PX Gen 2 battery configuration provides the best size/ runtime ratio.
Management and Cybersecurity
  • Innovative graphical LCD display brings all operating information at a glance. It also enhances commissioning and configuration capabilities.
  • 5PX Gen 2 is compatible with Eaton's Gigabit network management card, which provides Dual cybersecurity certifications (UL 2900-1 & IEC 62443-4-2) and enables connection to remote monitoring solutions safely.
  • Together with 5PX Gen 2, Eaton Gigabit network management card allows both remote UPS settings and remote firmware upgrade to ensure easy deployment (fleet management) and reduced maintenance cost.
  • 5PX Gen 2 monitors energy consumption right down to the managed outlet groups. kWh values can be monitored using the LCD or Eaton's Intelligent Power Software.
  • Eaton's Intelligent Power Software seamlessly integrates with leading virtualisation environments and cloud orchestration tools
Availability and flexibility
  • 5PX Gen 2 2200VA & 3000VA are available in RT2U format (optimised for rack mounting) or RT3U (for tower or short-depth racks). Pedestal and rail kits are included with all models.
  • 5PX Gen 2 Load segment control enables prioritised shutdowns of non-essential equipment to maximise battery runtime for critical devices (2 groups).
  • Eaton ABM® battery management technology uses a threestage charging technique that optimises battery health and extends lifetime by up to 50%.
  • Up to 4 external hot-swappable battery modules can be added for longer power availability

  • Warranty
    • Limited Warranty
    • 3 Year

  • Technical Information
    • Plug/Connector Type
    • IEC 60320 C20 (16A)
    • Receptacle Type
    • IEC 60320 C13 (10A)
    • IEC 60320 C19 (16A)
    • Receptacle Detail
    • 8 x IEC 60320 C13 (10A)
    • 2 x IEC 60320 C19 (16A)
    • Phase
    • Single Phase
    • Application/Usage
    • Network
    • Server
    • IT
    • Switch
    • Router
    • Storage Device
  • Power Description
    • Load Capacity (VA)
    • 3 kVA
    • Load Capacity (Watt)
    • 3 kW
    • Input Voltage
    • 120 V AC
    • 230 V AC
    • Input Voltage Range
    • 150 V AC - 294 V AC
    • 160 V AC - 294 V AC
    • Output Voltage
    • 200 V AC
    • 208 V AC
    • 220 V AC
    • 230 V AC
    • 240 V AC
    • Input Frequency
    • 70 Hz
    • Output Frequency
    • 60 Hz
    • Waveform Type
    • Pure Sine Wave
  • Management
    • Network Management
    • Relay-MS Card
    • Network-M3 Card
  • Controls/Indicators
    • Status Indicators
    • Graphical LCD Display:
      • UPS Status
      • Measurements
  • Interfaces/Ports
    • Serial Port
    • Yes
    • Network (RJ-45)
    • Yes
    • USB (HID Compliant) Port
    • Yes
  • Battery Information
    • Hot Swappable
    • Yes
    • Replaceable Battery
    • Yes
  • Environmental Conditions
    • Maximum Operating Temperature
    • 40°C
    • Sound Emission
    • 40 dB
  • Physical Characteristics
    • Height
    • 129 mm
    • Width
    • 438 mm
    • Depth
    • 483 mm
    • Rack Height
    • 3U
    • Form Factor
    • Rack/Tower
    • Weight (Approximate)
    • 31.10 kg
  • Miscellaneous
    • Package Contents
      • Pedestal
      • Rail Kits
    • Energy Star
    • Yes
    • Environmentally Friendly
    • Yes
    • Energy Efficiency Certification
    • ENERGY STAR 2.0
