8373 IP Zone Paging Adapter

The PoE 8373 IP Zone Paging Adapter provides a dry page output to a traditional zoned amplifier thereby offering a seamless bridge from VoIP to a legacy analog voice paging / public address PA system. The 8373 eliminates the need for a legacy zone controller however the paging adapter can also be deployed to add page zones to an existing single zone system. Three 3 zones are configurable on the paging adapter which can be expanded using multicast. A contact closure is also available on the device.

The 8373 paging adapter is a fully compliant 3rd party SIP endpoint. As a result this IP paging adapter is compatible with most hosted / cloud and premise-based VoIP telephone systems.

• Three zone IP paging adapter for public address PA.
• Isolated and balanced line output eliminates hum / noise to a traditional amplifier.
• Configurable line output supports amplifier input impedance between 600 Ohm and 10 kOhm.
• Eliminates a legacy zone controller and the need for an FXS port or ATA and telephone answering device hardware.
• Simultaneously multicast to IP endpoints and provide line output audio to support both IP and analog infrastructure as one unified public address PA system.
• Wideband HD voice for high intelligibility speech.
• Configuration via user friendly web interface or auto-provisioning.
• Secure SIP using TLS and SRTP.
• PoE IEEE 802.3af.
• Ideal for integrating legacy analog public address PA systems in education retail manufacturing transport terminals i.e. airports bus and rail stations healthcare government and other commercial environments.
